Heavy-Duty Mild Steel Bucket Elevator

Specifications

• Construction: Mild Steel

• Overall Length: 35' 4"

• Discharge Height: 30' 6"

• Bucket Material: Polyethylene

• Bucket Size: 7" × 9"

• Head Section: Centrifugal discharge

• Boot Section: Heavy-duty boot with cleanout access

• Drive: V-belt gear reducer drive (motor included if available)

• Inspection Doors: Multiple access covers on head and boot

• Safety: Ladder with safety cage

• Condition: Used

Estimated Capacity

• Approximately 6-10 tons per hour of wood pellets (45 lb/cu ft)

• Capacity varies with belt speed, bucket spacing, and material characteristics.

Description

Heavy-duty industrial bucket elevator constructed from mild steel with a 30'6" discharge height and 35'4" overall length. Equipped with durable 7" × 9" polyethylene buckets, making it suitable for conveying wood pellets, livestock feed, grain, fertilizer, seed, and many other free-flowing bulk materials.

The elevator features a robust boot section, centrifugal discharge head, ladder with safety cage, inspection covers, and belt-driven gear reducer. Its heavy welded construction makes it well suited for agricultural and industrial applications.

Ideal for:

• Pellet plants

• Feed mills

• Grain handling

• Seed processing

• Fertilizer facilities

• Bulk material conveying systems
