480v 3 Phase Transformer to 120/220v Single Phase
3 Phase Transformer
$2250.00
Specification | Value |
|---|
Manufacturer | Federal Pacific |
Catalog Number | T48LH2D-75 |
Type | Dry-type, ventilated, 3-phase transformer |
Power Rating | 75 kVA |
Primary Voltage | 480V Delta |
Secondary Voltage | 240V Delta / 120V High Leg (Center Tap) |
Frequency | 60 Hz |
Insulation Class | 220°C |
Temperature Rise | 150°C |
Ambient Rating | 40°C max |
Approximate Weight | 541-685 lbs |
Current Capacity
At full load:
Primary (480V): about 90 amps
Secondary (240V): about 180 amps
