Redline Belt Conveyor

7' horizontal and 7' incline section, 24" wide belt

$7000.00

Redline Portable Belt Conveyor

General Specifications

Specification

Value

Manufacturer

Redline Systems

Equipment Type

Portable Troughed Belt Conveyor

Belt Width

24 in.

Overall Length

14 ft

Belt Type

Chevron Cleated Rubber Belt

Frame Construction

Heavy-duty welded steel

Drive Motor

2 HP TEFC Electric Motor

Drive

Shaft-mounted worm gear reducer

Support

Portable frame with flotation tires

Belt Tracking

Adjustable take-up tail pulley

Condition

Never Used

Estimated Capacity

Material

Estimated Capacity

Wood Pellets

80–130 TPH

Animal Feed

90–140 TPH

Grain

110–180 TPH

Fertilizer

90–150 TPH

Wood Chips

60–110 TPH

Sand / Aggregate

70–125 TPH

Applications

Suitable for conveying:

  • Wood pellets

  • Animal feed

  • Grain

  • Seed

  • Biomass

  • Fertilizer

  • Sand

  • Aggregate

  • Recycled materials

  • Wood chips

Features

  • Heavy-duty industrial construction

  • 24-inch chevron cleated belt for inclined conveying

  • Low-maintenance shaft-mounted gear reducer

  • Portable design with flotation tires

  • Adjustable belt tracking

  • Fully welded steel frame

  • Compact 2 HP drive for energy-efficient operation

  • Suitable for indoor or outdoor installation

Estimated Weight

  • Approximately 1,400–1,800 lbs

Electrical

  • Motor: 2 HP

  • Power: 230/460 Volt, 3 Phase

  • Frequency: 60 Hz
