LMG 500-TON HYDRAULIC COMPRESSION PRESS Model: 500HD3724841 | Serial: 18829

LMG 500-TON HYDRAULIC COMPRESSION PRESS

Model: 500HD3724841 | Serial: 18829

GENERAL DESCRIPTION

Heavy-duty LMG (Lawton/Trinks lineage) hydraulic compression press

designed for high-force industrial molding applications. This unit was

previously utilized in the production of recycled plastic pallets and is built

for continuous-duty operation with large-format molds.

The press features a robust frame, large platen area, and a properly sized

hydraulic system delivering both high force and practical cycle speeds for

production environments.

KEY SPECIFICATIONS

Press Capacity

● Manufacturer rated: 500 tons

● Verified cylinder bore: 18 inches

● Calculated output:

○ ~381 tons @ 3000 PSI

○ ~500 tons @ ~4000 PSI (design/peak rating)

Platen & Stroke

● Platen size: 48" x 60"

● Stroke Length: 28"+ (based on measured rod exposure)

Main Cylinder

● Bore diameter: 18 inches

● Heavy-duty single ram design

Hydraulic System

● Pump: Parker Denison P0100XS series vane pump (serial

#C14J282)

● Estimated displacement: ~100 cc/rev

● Estimated flow rate: ~45–50 GPM

● Typical operating pressure: 2000–3000 PSI

● Hydraulic Power Unit includes:

○ Kundinger reservoir

○ Oil cooling system (radiator/heat exchanger)

○ Filtration and manifold system

Motor & Electrical

● Main motor: 100 HP WEG

● 460 V / 3-phase

Controls

● PLC-controlled system (not CNC)

● Standard industrial control architecture (likely Allen-Bradley or similar)

● Designed for controlled pressure, dwell, and cycle sequencing

● The control panel is off site from the unit and will ship separately

PERFORMANCE (ESTIMATED)

● Ram speed: estimated at 0.7 inches/second under load

● Stroke time: ~35–45 seconds (one direction full distance)

● Cycle time: ~60–120 seconds depending on:

○ Pressure stage

○ Dwell time

○ Rod retraction requirement

○ Previous user quoted the unit being able to produce 1

million plastic pallets per year at peak performance

APPLICATION HISTORY

● Previously used in recycled plastic pallet manufacturing

● Suitable for:

○ Plastic and composite compression molding

○ Large-format part production

○ Industrial forming applications requiring high tonnage

DIMENSIONS & WEIGHT (ESTIMATED)

● Total system weight: I will verify but I believe it is at least 58,000 lbs

(includes main press, platen and hydraulic units separated in three

pieces.)

● Approximate dimensions:

○ Main Press - 20.5x11.5x8.5 feet (including hoses etc)

○ Platen (mounts to rod) - 4.5x3x8.5 feet

○ Pump/Reservoir - 12.5x8.5x7 feet (including mounting legs)

RIGGING & TRANSPORT

● Recommended Lifting Capacity: 110 ton crane is what we used to

unload it. It was around $6000.

● Transport via:

○ Low boy 48 foot semi trailer

● Oversize/overweight permits required
